Published date: October 19, 2022
Now we evaluate speed of charge and supply of electrical current to your home, both very important factors when choosing the best Level 2 EV charging option.
All Level 2 chargers use 240-volt outlets, so charging time varies depending on the charger’s amperage.
Before selecting a Level 2 charger, make sure to check your vehicle’s technical sheet for the amount of kilowatts the vehicle’s onboard charger can accept. You should then divide that number by 240 to know what amperage your charger should have:
I(A) = (P(kW) * 1000) / V(V)
For example, for a Ford Mach-e, max AC rate is 11.5kW.
I(A) = (11.5kW * 1000) / 240V = 48 amps
Most Plug-in Hybrid Electric Vehicles (PHEVs) can accept 16-32 amps, while most electric vehicles can accept 32 - 48+ amps. All else equal, the more amperage flowing into the vehicle, the faster the charge time. However, we do not recommend installing a charger with more amps than your vehicle can accept.
Many homes pull either 60, 100 or 200 amps of current. The Level 2 EV charger will usually need 30-50 amps, which would be fine if it is the only appliance plugged in, however other appliances need amps too. Further, the National Electrical Code requires an electrical circuit to be rated for 25% greater amperage than your charger’s output. For example, if you want to buy a 40-amp Level 2 charger, you’ll need a circuit breaker that’s rated for at least 50 amps.
Your panel will also need to have enough physical space for the charger. Circuit breakers will need to be available for the charger. A certified electrician will be able to tell if there is enough space.
